JIS F7409 16K Marine Bronze Screw Down Check Valve
Product Details
MATERIALS
Body | Bronze |
Bonnet | Bronze or Brass |
Disc | Bronze |
Seat | Bronze |
Stem | Brass |
Handwheel | Cast Iron |
TECHNICAL DATA
Manufactured in accordance to JIS F7400 • Flanges as per JIS B2220 – 16K
TESTS
Test Liquid | Water at Room Temp |
Body Test | 38 Kg |
Seat Test | 23 Kg |
DIMENSIONS
IMPA CODE | Size | L | D | C | No. | h | t | H | D2 |
75 10 71 | 15 | 110 | 95 | 70 | 4 | 15 | 12 | 130 | 80 |
75 10 72 | 20 | 120 | 100 | 75 | 4 | 15 | 14 | 140 | 100 |
75 10 73 73 | 25 | 130 | 125 | 90 | 4 | 19 | 14 | 160 | 125 |
75 10 74 10 74 | 32 | 160 | 135 | 100 | 4 | 19 | 16 | 170 | 125 |
75 10 75 10 75 | 40 | 180 | 140 | 105 | 4 | 19 | 16 | 190 | 140 |
